PRODUCT

Handheld transmission laser welding machine

MODEL: BY-TW-HA

THE LASER WAVELENGTH:1064nm

MAX MONOPULSE ENERGY:50J

LASER WELDING DEPTH:≤1.0 mm

FIBER LENGTH:5m

SPOT ADJUSTMENT RANGE :0.2-3.0mm

APPLICATION

Used in welding of aluminum, copper, zinc, gold, silver and other alloys and alloys, steel and other alloy materials, automotive parts industry: engine cylinder head gasket, hydraulic tappet seal welding, filter seal welding, spark plug welding, valve push rod welding, anti-collision airbag electric detonator seal welding, crankshaft or cylinder liner heat treatment.

FEATURES

It adopts imported double-lamp gold-plated concentrating cavity, with high reflectivity, high energy, high temperature resistance, corrosion resistance, long service life, good beam quality and more uniform welding,

Hand-held welding is more convenient and fast, for large, difficult to move products can be long-distance welding, because of the transmission of optical fiber, laser energy is more concentrated, can penetrate more than 2mm stainless steel metal, stainless steel products spot welding, butt welding, Stack welding, sealing welding, complete the welding of complex plane straight lines, arcs and arbitrary tracks,

The welding efficiency is high, the effect is good, the operation is simple and convenient, the laser head can also be fixed, and the product can be automatically welded.

All the optical fibers are made of imported materials, and the durability is good. The beam quality of the optical fiber transmission is better, the solder joints are more uniform, and the penetration depth is also better.

PARAMETERS
Maximum laser power 400W 600W
The laser wavelength 1064nm
Max monopulse energy 50J
Condenser reflector Dual lamp focusing chamber
wave mode Double pulse combination
Laser welding depth ≤1.0mm
The pulse width 0.2-10ms
Continuous laser welding frequency ≤50Hz
Spot adjustment range 0.2-3.0mm
fiber length 5m
Rated power 12KW
Cold power of cold water mechanism 3P
Demand for electricity 380V±5V 50Hz/60A /220V±5V 50Hz/40A
External dimensions/net weight Host computer: 690*1300*1070mm
cooling-water machine:  800*640*1200mm 127kg
